Part List
-
Part list details
Type of cableCable LI9Y 3 x 0,34mm² PURConnector 1M12 PPi A-cod 4p an/- m/- for 0° matingConnector 2M12 PPi A-cod 3p an/- f/- for 0° mating
Identification
- Category 系統佈線
- Series 圓形連接器 M12
- Element 電纜組裝
- Specification 兩端預接
-
Connector 1
M12 A編碼公頭 直式一體成型Inner PushPull
-
Connector 2
M12 A編碼母頭 彎式一體成型Outer PushPull
- Type of cable 銅質電纜 （圓型）
- Description of the cable 無鹵素
Version
- Cable length 5 m
- Number of cores 3
- Core structure 3x 0.34 mm²
- Termination method 壓接針
- Shielding 無屏蔽
- Number of contacts 3
- Coding A編碼
Technical characteristics
- Rated current 4 A
- Rated voltage 250 V
-
Limiting temperature
-25 ... +80 °C 已移動-40 ... +80 °C 未移動
- Degree of protection acc. to IEC 60529 IP65 / IP67 插配狀態
- Cable diameter 4 mm
-
Minimum bending radius
10x 電纜直徑 （反复彎曲）5x 電纜直徑 （單次彎曲）
Material properties
- Material (cable) PUR (聚氨酯)
- Colour (cable) RAL 7021 (黑/灰)
- RoHS 符合
- ELV status 符合
- China RoHS e
- REACH Annex XVII substances 不包含
- REACH ANNEX XIV substances 不包含
- REACH SVHC substances 不包含
- California Proposition 65 substances 不包含
Specifications and approvals
- Approvals CE
Commercial data
- Packaging size 1
- Country of origin 德國
- European customs tariff number 85444290
- eCl@ss 27,060,311.00
- ETIM EC001855
- UNSPSC 24.0 26121604
