Resumen de caracterísiticas
Shell housing, 15 mm, Thermoplastic, Fibre-glass reinforced
Detalhes do produto
Identification
- Category Accessories
- Series DIN 41612
-
Identification
Type FType HType MH
- Type of accessory Shell housing
- Description of the accessory 15 mm
Version
- Version Side entry
- Number of cable entries 2
- Cable entry 2x
- Strain relief With cable clamps
- Locking type Locking levers or locking screws
- 2 parts Yes
- Separable Yes
Technical characteristics
- Limiting temperature -40 ... +125 °C
- Degree of protection acc. to IEC 60529 IP20
- Isolation group IIIa (175 ≤ CTI < 400)
Material properties
- Colour (hood/housing) RAL 7032 (pebble grey)
-
Material (accessories)
ThermoplasticFibre-glass reinforced
- Material flammability class acc. to UL 94 V-0
- RoHS compliant
- ELV status compliant
- China RoHS e
- REACH Annex XVII substances Not contained
- REACH ANNEX XIV substances Not contained
- REACH SVHC substances Not contained
- California Proposition 65 substances Yes
Specifications and approvals
- Railway classification F1/I2 acc. to NFF 16-101/102
Commercial data
- Packaging size 10
- Net weight 30 g
- Country of origin Germany
- European customs tariff number 85389099
- GTIN 5713140011250
- eCl@ss 27440292 Connector component (accessories)
- ETIM EC002943
- UNSPSC 24.0 39121400
