Identification
- Category 上売/底座
- Series of hoods/housings Han® HPR enlarged
- Type of hood/housing 上壳
Version
- Size 16 HPR enlarged
- Version 没有出线口
- Locking type 螺钉锁扣
- Field of application 用于恶劣室外环境的上壳/底座
- Details 当使用尺寸为 B 的 Han®标准插芯或 Han-Modular® 铰链框架时，请单独订购适配器 09400009960。
Technical characteristics
- Tightening torque (screw locking) 4 Nm
- Limiting temperature -40 ... +125 °C
- Note on the limiting temperature 用作符合 IEC 61984 标准的连接器。
-
Degree of protection acc. to IEC 60529
IP65IP68IP69 / IPX9K，符合 ISO 20653
-
Type rating acc. to UL 50 / UL 50E
44X12
Material properties
-
Material (hood/housing)
压铸铝防腐蚀
- Surface (hood/housing) 粉末涂层
- Colour (hood/housing) RAL 9005（乌黑）
- Material (locking) 不锈钢
- RoHS 符合
- ELV status 符合
- China RoHS e
- REACH Annex XVII substances 不包含
- REACH ANNEX XIV substances 不包含
- REACH SVHC substances 不包含
- California Proposition 65 substances 有
-
California Proposition 65 substances
镍萘
- Fire protection on railway vehicles EN 45545-2 (2020-08) + A1 (2023-10)
-
Requirement set with Hazard Levels
R1 (HL 1-3)R7 (HL 1-3)
Specifications and approvals
Commercial data
- Packaging size 35
- Net weight 666.4 g
- Country of origin 中国
- European customs tariff number 85389099
- GTIN 5713140173064
- eCl@ss 27440202 长方形连接器的外壳
- ETIM EC000437
- UNSPSC 24.0 39121466
