产品详情
Identification
- Category 连接器
- Series RJ45
- Series of hoods/housings Han A®
- Element 电缆连接器
Version
- Termination method 刺破接线
- Size 3 A
- Shielding 完全屏蔽360°屏蔽触点
- Number of contacts 8
- Pack contents 连接器插芯
Technical characteristics
- Conductor cross-section 0.08 ... 0.22 mm² 绞线
- Conductor cross-section [AWG] AWG 28/7 ... AWG 24/7 绞线
- Wire outer diameter ≤1.05 mm
- Transmission characteristics Cat. 6 E 级，到 250 MHz
-
Data rate
10 Mbit/s 100 Mbit/s 1 Gbit/s 2.5 Gbit/s 5 Gbit/s 10 Gbit/s
- Limiting temperature -40 ... +70 °C
- Storage temperature +5 ... +50 °C
- Cable diameter 6.5 ... 9.5 mm
Material properties
- RoHS 符合
- ELV status 符合
- China RoHS e
- REACH Annex XVII substances 不包含
- REACH ANNEX XIV substances 不包含
- REACH SVHC substances 有
- REACH SVHC substances Potassium 1,1,2,2,3,3,4,4,4-nonafluorobutane-1-sulphonate
- ECHA SCIP number a4a9de28-6060-4c0d-b79b-5842f7db41be
- California Proposition 65 substances 有
-
California Proposition 65 substances
铅镍
Specifications and approvals
Commercial data
- Packaging size 1
- Net weight 31.78 g
- Country of origin Romania
- European customs tariff number 85366990
- GTIN 5713140058682
- eCl@ss 27440205 Contact insert for industrial connectors
- ETIM EC000438
- UNSPSC 24.0 39121522
