属性概述
保护盖
用于中间壳, + 2x PE
尺寸: 34 HPR
螺钉锁扣
材料 (上壳/底座): 压铸铝, 防腐蚀
粉末涂层
RAL 9005（乌黑）
防护等级: IP65, IP68, IP69 / IPX9K，符合 ISO 20653
产品详情
Identification
- Category Accessories
- Series of hoods/housings Han® HPR EasyCon
- Type of accessory Protection cover
-
Description of the accessory
for carrier hoods+ 2x PE
Version
- Size 34 HPR
- Locking type Screw locking
Technical characteristics
-
Tightening torque
6 Nm Protection cover15 Nm PE screw6 Nm Fixing screws
- Limiting temperature -40 ... +125 °C
-
Degree of protection acc. to IEC 60529
IP65IP68IP69 / IPX9K acc. to ISO 20653
Material properties
-
Material (hood/housing)
Aluminium die-castCorrosion resistant
- Surface (hood/housing) Powder-coated
- Colour (hood/housing) RAL 9005 (jet black)
Specifications and approvals
- Approvals DNV GL
Commercial data
- Packaging size 1
- Net weight 1,629 g
- Country of origin China
- European customs tariff number 85389099
- GTIN 5713140901896
- eCl@ss 27440208 Cap for industrial connectors
- ETIM EC002314
- UNSPSC 24.0 39121467
