Identification
- Category 连接器
- Series 圆形连接器 M12
- Element PCB适配器
- Specification 直式
Version
- Termination method 回焊焊接接线方式 (SMT)
- Gender 母头
- Shielding 屏蔽
- Number of contacts 8
- Coding X编码
- Details 单独订购底座
- Pack contents 每卷 75 个
Technical characteristics
- Rated current 0.5 A
- Rated voltage 48 V
- Pollution degree 3
- Transmission characteristics Cat. 6A EA 级，到 500 MHz
-
Data rate
10 Mbit/s 100 Mbit/s 1 Gbit/s 2.5 Gbit/s 5 Gbit/s 10 Gbit/s
- Insulation resistance >108 Ω
- Limiting temperature -40 ... +85 °C
- Mating cycles ≥ 100
Material properties
- Material (insert) 液晶聚合物 (LCP)
- Material (contacts) 铜合金
- Surface (contacts) 镍表面镀金 界面端
- Material flammability class acc. to UL 94 V-0
- RoHS 符合豁免标准
- RoHS exemptions 6(c)：铜合金含铅量高达 4 %
- ELV status 符合豁免标准
- China RoHS 50
- REACH Annex XVII substances 不包含
- REACH ANNEX XIV substances 不包含
- REACH SVHC substances 有
- REACH SVHC substances 铅
- ECHA SCIP number 0d7d3693-d625-47ab-934a-d241bf72c86e
- California Proposition 65 substances 有
- California Proposition 65 substances 铅
Specifications and approvals
- Specifications IEC 61076-2-109
Commercial data
- Packaging size 1
- Net weight 8.56 g
- Country of origin 捷克
- European customs tariff number 85366990
- GTIN 5713140228818
- eCl@ss 27460201 印刷电路板连接器
- ETIM EC002637
- UNSPSC 24.0 39121415
